HJ-LED34
-
LAMP
1.Description
Ultra-slim hollow mesh design, barrier-free laminar air flow through the ultra-slim hollow mesh design, which will meet with the requirements of modern purified laminar flow operating room. During a long operation, the surgeon requires a strong, clear, non-glaring light to reach comfortable visual effect . The optical design of this product fully consists with the physiological structure of the eyes to ensure maximum comfort for the eyes. When the surgical shadowless lamp is turned on, it is initialized to the 71% brightness that is most suitable for vision. And the brightness can be adjusted freely in the range of 5%-100%, and the doctor's eye fatigue can be compensated during the operation. The digital memory function will automatically record the appropriate illuminance, and it is no need to adjust it when it is turned on again.
2.Technical parameters
Name
HJ-LED4 lamphead
HJ-LED3 lamphead
Light Head Diameter
740mm 4 parts panel
740mm 3 parts panel
Illuminance Range
40000-160000x,10 levels subdevision control
10 levels subdevision control,
10 levels subdevision control
Maxium Lights Intensity (Lux)
160000 lux
160000 lux ±2%
Spot Size
18-28cm,5 levels
subdevision control18-28cm,5 levels
subdevision controlColor Rendering Index
≧96
≧96
Depth of Illumination
150cm±5%
130cm±5%
LED Lifecycle
>60000hour
>60000hour
Radiation power
< 500w/m2
< 420w/m2
Excellent brightness
Excellent dilution effect
Ergonomic design
Detachable and autoclavable main handle
Non UV radiation and cold light
Excellent illumination depth
4,300k color temperature
Intuitive and easy-to-use control method
Focus lamp
Lightweight suspension system
Strength
160,000 lux (level 6)
Color temp. index
95
Multiple installation options
ceiling, mobile, double ceiling installation
LED life
60,000hr
LED
84
CRI
95
Color temperature
3,800k / 4,300k / 4,800k
Head circumference
23.6 inches
Focus size
7.8 inches (round)/11.8 inches (round)
Focal length
1M
Illumination
Max 160,000 Lux
Input power
100-240Vac, 60Hz
Power consumption
125 W
LED life
60,000 hours
3.Model list
MODEL
PRODUCT
HJ-LED3 lamphead
LED operating single lamphead with armtube
HJ-LED4 lamphead
LED operating single lamphead with armtube
HJ-LED33 lamphead
LED operating double lamphead with armtube
HJ-LED34 lamphead
LED operating double lamphead with armtube
HJ-LED44 lamphead
LED operating double lamphead with armtube
4.Package and delivery
